Envelope Example

This example demonstrates using the daisy for an ADSR envelope. This example shows off the ability to output audio rate control voltage signals from the CV output pins of the DAC.

Controls

Pin Name	Pin Location	Function	Comment
CV 1	C5	Attack Time	Range is from instant to 1 second
CV 2	C4	Decay Time	Range is from instant to 1 second
CV 3	C3	Sustain Level	Range is from 0v to 5V for sustain stage
CV 4	C2	Release Time	Range is from instant to 1 second
Gate In 1	B10	ADSR Gate	Input for engaging the envelope
Button	B7	ADSR Button	Engages the envelope while pressed

---

Hardware Test

Hardware verification test.

This is set up to use the patch.Init() hardware to verify the Patch SM is functioning as expected.

To verify the various functionality:

• USB Serial port is used to print data
  • ADC Values for all 12 ADCs are printed (four of these are on the expander bank)
  • Gate input values
  • B7 and B8 (check actual pin names) values based on toggle/button position
  • SDRAM Pass/Fail
  • QSPI Pass/Fail
  • SDMMC Pass/Fail
• If an SD Card is connected at bootup the it will write, and readback a text file to verify it functions.
• Audio will be passing through. IN_L is connected to IN_R when on the hardware when no jack is plugged into the IN_R jack.
• The LED and CV out will be generating 1Hz ramp waves.
• The Gate Outputs will be outputting Squarewaves at 500mHz (one pulse per two seconds)

Checking the values via USB

THIS SERIAL MONITOR SCRIPT HAS NOT BEEN ADDED YET.

Included is a script that will open a serial monitor.

Running test.sh (or test.bat on windows) with python installed a terminal will open and start printing.

By double-clicking, or running with no arguments, the test will find the first available COM port connected and connect to it. This may not always be the

Daisy.

You can pass in an argument with the name of the COM Port (usually checked in your PCs Device Manager)

This will look something like:

% Windows

test.bat COM17

# Mac/Linux

./test.sh usbmodem12345678

---

Looper

Author: nbeserge

Description: Simple Looper for Patch SM.
Includes controls for record on / off / clear, Input Volume, and Loop Volume.
The output is a 50/50 mix of the post gain input and loop signals.

If you are using the patch.Init(), the controls are already connected as they should be.

If you are using a bare Patch SM, refer to the 1.x figures in the Patch SM Datasheet.

Controls

Pin Name	Pin Location	Function	Comment
CV_1	C5	Input Level	Connect a potentiometer here.
CV_2	C4	Loop Level	Connect a potentiometer here.
B7	B7	Record Toggle	Connect a tactile switch here. Press to toggle recording, hold to clear.
OUT_R	B1	Audio Out R	Connect a jack here.
OUT_L	B2	Audio Out L	Connect a jack here.
IN_R	B3	Audio In R	Connect a jack here.
IN_L	B4	Audio In L	Connect a jack here.

---

Pass thru Example

This is a simple example of passing audio input through the Daisy Patch SM.

This is a great starting point for new projects using this board.

To use this project as a template for your own project you can use the following helper.py command:

./helper.py copy MyProjects/MyAwesomeNewProject –source patch_sm/PassthruExample

Controls

None

---

Random CV Example

This example demonstrates basic usage of the CV Outputs on the Daisy Patch SM.

Both CV outputs will output the same random voltage.

Controls

None

---

Reverb Example

This example shows how to set up a simple reverb effect.

Controls

Pin Name	Pin Location	Function	Comment
CV_1	C5	Reverb Time	Controls the size of the reverb
CV_2	C4	Reverb Dampening Frequency	Range is from 1kHz to 19kHz
CV_3	C3	Input Level	Controls the amount of dry signal passing through to the output
CV_4	C2	Send amount	Controls the amount of dry signal sent to the reverb

The _comments.cpp file is identical to the main file, but has detailed comments explaining each piece of the source code.

---

Simple Oscillator

Basic sine wave oscillator.

This example demonstrates the both the basics of setting up an oscillator as well as using calibrated pitch tracking for accuracy with 1V/Octave signals.

To keep this example on the simpler side, the calibration itself is handled in another program.

See the patch_sm/VoctCalibration example, which will go through the process of calibrating the CV_5 input.

Controls

Pin Name	Pin Location	Function	Comment
CV_1	C5	Coarse Tuning	Sets the pitch of the oscillator
CV_5	C6	1V/Octave Input	Musical pitch tracking input

---

TripleSaw Example

This example shows how to make a complex oscillator voice using three bandlimited sine waves.

Controls

Pin Name	Pin Location	Function	Comment
CV_1	C5	Coarse Tuning	Tunes the base frequency of all three oscillators
CV_2	C4	Fine Tuning	Fine tune adjustment of base freq. for all three oscillators
CV_3	C3	Detune Amount	Adjusts the amount of detuning between all three voices
CV_5	C6	1V/Octave Input	Musical pitch tracking input

The _comments.cpp file is identical to the main file with detailed comments of each piece of the source code.
